1973-1979 Corvette Headlamp Door Vacuum 12"x18" Laminated Poster


Price: $12.50
Item Number: 2771806
1973-1979 Corvette Headlamp Door Vacuum 12"x18" Poster
CAVEAT EMPTOR: includes a Full Color detailed schematic identifying all the various valves, relays, switches & hoses with instructions for all the Color Coded connections. Tested accurate decades ago. Published in USA. Bonus: laminated in 14 mil clear plastic which will not only stay clean, but will lay flat (not roll up).
FACT:
In sworn testimony for a US Federal Court deposition, Zip Corvettes artist swore that he created each of their vacuum hose drawings. Remarkably he also swore that he had never looked under the hood of any Corvettes. Coincidentally if you hook up the hoses to match that Zip Corvette illustration, neither the headlamps nor the wiper door will open. Who would have guessed that?
