LATE 1969 Corvette Headlamp & Wiper Door Vacuum 12"x18" Poster
IDENTIFICATION: Late 1969 has the Wiper Door Relay Valve mounted to the Left side of the firewall.
CAVEAT EMPTOR: includes a Full Color detailed schematic identifying all the various valves, relays, switches & hoses with instructions for all the Color Coded connections. Tested accurate decades ago. Published in USA. Bonus: laminated in 7 mil clear plastic which will not only stay clean, but will lay flat (not roll up).
View the Bottom of These Posters -
FACT:
In sworn testimony for a US Federal Court deposition while under oath
david walker testified he climbed up a step ladder over the open hood of
a Corvette to take a photo of the vacuum hoses. He then claimed, that
he stood behinds the zip "Artist" who drew and connected all the hoses on a
computer screen as directed by david. What as COS was revealed from that fable.
In another sworn testimony for a US Federal Court deposition zip's
"Artist" swore under oath that he created each of their vacuum hose
drawings. Remarkably he also swore under oath that he had never looked
under the hood of any Corvettes. Coincidentally if you hook up the hoses
to match that zip Corvette illustration, neither the headlamps nor the
wiper door will open. Who would have guessed that? What a bunch of
dopes.
Then zip copyrighted every 68-82 illustration that had the fatal
errors that prevented the system from operating. Decades after that
debacle, Lap Dog just abbott was hired and he blamed all the errors in
copying faulty GM illustrations. I wonder what the next excuse will be.
DocRebuild created these vacuum hose illustrations & he looked under the hood of many, many, many real Corvette's.
