1971-1972 Corvette Headlamp & Wiper Door Vacuum 12"x18" Poster
CAVEAT EMPTOR: includes a Full Color detailed schematic identifying all the various valves, relays, switches & hoses with instructions for all the Color Coded connections. Tested accurate decades ago. Published in USA. Bonus: laminated in 7 mil clear plastic which will not only stay clean, but will lay flat (not roll up).
FACT: In sworn testimony for a US Federal Court deposition, Zip Corvettes artist swore under oath that he created each of their vacuum hose drawings. Remarkably he also swore under oath that he had never looked under the hood of any Corvettes. Coincidentally if you hook up the hoses to match that Zip Corvette illustration, neither the headlamps nor the wiper door will open. Who would have guessed that? What a bunch of dopes.
Under oath, David Walker testified he climbed up a step ladder over the open hood of a Corvette to take a photo of these hoses. He then claimed, that he stood behinds the artist who drew and connected all the hoses on a computer screen. Then zip copyrighted every 68-82 illustration that had the fatal errors that prevented the system from operating.
Then decades after that debacle, Just Abbott was hired and then he blamed all the errors in copying faulty GM illustrations. I wonder what the next excuse will be.
DocRebuild created these vacuum hose illustrations & he looked under the hood of many, many, many real Corvette's.
